Pipeline Cleaning Robot K6
Pipeline Cleaning Robot K6
Pipeline Cleaning Robot K6
Pipeline Cleaning Robot K6

Pipeline Cleaning Robot K6

This one has a lot of equipment and is used for cleaning in hospitals and dust-free workshops.Its fine cleaning makes the project better completed, and the fuselage has lifting function, which can be on the pipe wall.By cleaning and vacuuming with two circular brushes, the minimum can be reduced to 250mA, and the maximum can be increased to 700 Millimeter. Personnel can operate on the computer to complete the work.

In the area of AI, replacing human with technology has become the mainstream technology direction all over the world. Automation equipment can avoid personal injury to technicians in the workplace, no fatigue, and can work for a long time, so it is widely loved by the engineering team.

This one has a lot of equipment and is used for cleaning in hospitals and dust-free workshops.Its fine cleaning makes the project better completed, and the fuselage has lifting function, which can be on the pipe wall.By cleaning and vacuuming with two circular brushes, the minimum can be reduced to 250mA, and the maximum can be increased to 700 Millimeter. Personnel can operate on the computer to complete the work.



Robotparameters
Weight: 15kg
Body material 320mm * 260mm * 280mm
Operating voltage: DC / 24 V
8mm steel plate
Track: high magnetic and
stainless steel replaceable track
Tower mechanical two axis
mode: horizontal and vertical
Driving mode: servo
analog wireless control
Driving torque 300kg
Movement mode: 2 * 2 drive (powerful permanent
magnet double track drive)
Speed: 3-4 M / min (standard
speed 3.765 M / min)
Camera: front and rear industrial corrosion-resistant
wide-angle large aperture 4K camera
Lighting: 4 * 3W astigmatic fog
piercing strong light LED lighting



Consoleparameters
Size: 360mm * 270mm * 187mm
Weight: 11kg
Video storage: up to 256gb SD card
Display mode: 10.2 inch color screen
high definition LCD screen
Videostorage mode: mode: mov format, synchronous
monitoring and recording system,
h265 compression,
3656 × 2664 video resolution
Operation mode: wired connection
Drivecontrol mode: manual remote control operation
/ computer automatic control
Security system: DC low voltage microcomputer control
leakage protection, line overload,
component safety system
