Handheld Laser Cleaning Machine

The laser cleaning machine includes a laser generator, handheld cleaning head and control system with multiple safety alarms and active safety power and light cut-off settings. The product can be adapted to all brands of fibre lasers; the optimised optical and water cooling design allows the laser head to work stably for a long time at 2000W.

REQUEST A QUOTE

Basic features: self-developed control system with multiple safety alarms, smaller size, flexible operation and easy to use.
More stable: all parameters are visible, the machine status is monitored in real time, problems can be avoided in advance and problems can be more easily investigated and solved to ensure the stable operation of the cleaning head.
Process: all parameters are visible, the cleaning quality is more perfect.
Stable and repeatable parameters: with a defined nozzle pressure and lens status, the process parameters are always repeatable as long as the laser power is stable. This greatly increases efficiency and also reduces operator requirements.

Model	LC-1000	LC-1500	LC-2000
Laser Power	1000W	1500W	2000W
Cleaning width	0-300mm	0-300mm	0-300mm
Laser Wave Length	1070nm	1070nm	1070nm
Collimator focal length	60mm	60mm	60mm
Protective lens	φ30X1.5mm	φ30X1.5mm	φ30X1.5mm
Focusing lens focal length	800mm	800mm	800mm
Maximum air pressure	0.4Mpa	0.4Mpa	0.4Mpa
Power Supply	220V/50HZ	220V/50HZ	220V/50HZ
Cooling System	Thermostatic Chiller	Thermostatic Chiller	Thermostatic Chiller
Chiller Tank Capacity	16L	16L	16L
Dimension	115X60X130cm	115X60X130cm	115X60X130cm
Net Weight	200kg	207kg	215kg
Gross Weight	265kg	272kg	280kg
