Hydraulic Sheet Metal Folding Machine
Hydraulic Sheet Metal Folding Machine
This machine can be found in a variety of industries such as metal furniture, electric lamps, vent duct, kitchen manufacturing, vehicle, shipping yard and light industry, etc.
This machine is used for folding the plate in the max thickness of 5mm, max length of 2000mm, 2500mm or 3100mm. The folding blade of the machine can be changed for different folding shape. The machine is driven by hydraulic system stably. Machine frame is of all welded steel plate construction with a long working life. The folding angle and blade gap can be adjusted quickly and easily. The auto hydraulic folding is easy for operating and safe, with single and step operation modes.
Hydraulic cylinder drive fixed bending sheet.
Hydraulic cylinder drives bending workpiece.
Manual positioning of the back gauge.
Folding tool is processed with high precision to ensure the straightness of bending.
The segmented bending die can be arbitrarily fixed according to the workpiece.
Adjust the bending angle according to the bending workpiece.
Front protection ensures operator safety.
| Model | W62Y-4X2500 | W62Y-4X3100 |
| Working Material | Mild steel sheet, Stainless steel sheet | |
| Folding Thickness | 0.5-4.0 mm | 0.5-4.0 mm |
| Folding Length | 2500 mm | 3100 mm |
| Folding Angle | 20-120° | 20-120° |
| Folding Blade Length | 2500 mm | 3100 mm |
| Max Open Height | 200 mm | 200 mm |
| Beam Swinging Angle | 0-123° | 0-123° |
| Hydraulic Capacity | 25 L | 25 L |
| Hydraulic Pressure | 8 Mpa | 8 Mpa |
| Dimension | 3585 x1067 x2093 | 4185 x1067x2093 |
| Weight | 6042 | 6542 |
